10.0M~1.5G 請在此填寫或選擇
(*填寫時需要加K/M/G)
請在此選擇
| 溫度頻差VS溫度范圍 | ±20ppm | ±25ppm | ±30ppm | ±50ppm | ±100ppm |
|---|---|---|---|---|---|
| -20~70℃ | |||||
| -40~85℃ | |||||
| -40~105℃ | |||||
| -40~125℃ |
Specs
所選參數Item
KD326DOutput Logic
LVDSNominal Frequency
左邊填寫Operating Voltage
左邊填寫Frequency Tolerance
±30ppmFrequency Stability
左邊選擇Operating Temperature
左邊選擇Output Level
--Current Consumption
--Jitter
0.2pS typ. 0.5pS max (12KHz~20MHz)Duty Cycle
45~55%Rise/Fall Time
0.8ns maxStart-up Time
10ms maxSpecial Requirement
左邊選擇Specs
所選參數Item
KD326DOutput Logic
LVDSNominal Frequency
Operating Voltage
Frequency Tolerance
±30ppmFrequency Stability
Operating Temperature
Output Level
--Current Consumption
--Jitter
0.2pS typ. 0.5pS max (12KHz~20MHz)Duty Cycle
45~55%Rise/Fall Time
0.8ns maxStart-up Time
10ms maxSpecial Requirement
有/無
